270 degree Panoramic design without barrier
Support up to 10 fans and 360mm radiator
Extremely functional
| Motherboard Support: ITX/M-ATX/ATX(Support BTF) | Reserved Fan Ports: |
| I/O Port: USB3.0x2 | Front: N/A |
| PCI Slots(fixed): x8（SupportVertical: x8) | Top: 3*120 or 3*140mm(Fan optional) |
| Chassis: L480*W245*H500mm | Support 120/240/280/360/420mm liquid cooler |
| Product: L486*W245*H520mm | Rear: 1*120mmor 1*140mm(Fan optional) |
| Grommets:7pcs(Include) | Support 120/140mm liquid cooler |
| PSU Port: Bottom /ATX (Max 220mm) | Motherboard:3*120mm or 3*140mm (Fan optional) |
| Max.VGA Card: 455mm(Fully compatible with 4090) | Support 120/240/280/360/420mm liquid cooler |
| Max.CPU Cooler: 185mm | PSU chamber:2*120mm (Fan optional) |
| Cable Management: 36mm | Bottom:1*120 or 1*140mm (Fan optional) |
| / | Drive Bays: 5.25" ODD x0 |
| / | 3.5" HDD x3 |
| / | 2.5" SSD x7 |
D430ZF-BLACK-详情1.jpgD430ZF-BLACK-详情2.jpgD430ZF-BLACK-详情3.jpgD430ZF-BLACK-详情4.jpgD430ZF-BLACK-详情5.jpgD430ZF-BLACK-详情6.jpg
