Visualized zoned cooling system
Superior heat dissipantion
Panoramic view
Support up to 8 fans
Motherboard Support: ITX/M-ATX/ATX/E-ATX(Support BTF) | Reserved Fan Ports: |
| I/O Port: USB3.0x2 | Front: N/A |
PCI Slots(fixed): x7 | Rear: 2*120mm(Fan optional) |
| M/B: ARGB logo included | Support 120mm liquid cooler |
| Chassis: L460*W285*H430mm | Motherboard:3*120mm or 2*140mm (Fan optional) |
Product: L460*W285*H450mm | Support 120/240/360mm liquid cooler |
| Carton: L607*W384*H570mm | Bottom:3*120mm or 3*140mm (Fan optional) |
PSU Port: Bottom/ATX | Drive Bays: 5.25" ODD x0 |
Max.VGA Card: 435m | 3.5" HDD x4 |
| Max.CPU Cooler: 163mm | 2.5" SSD x4 |
Cable Management: 96mm | Loading QTY: 20GP 180pc |
| / | 40HQ 470pcs |
