Functionality with seamless visuals
Perforated air vent PSU chamber
Support up to 360mm AIO Cooler
| Motherboard Support: ITX/M-ATX/ATX Support BTF M/B | Reserved Fan Ports: |
| I/O Port: USB3.0x2+HD AUDIO | Front: N/A |
| PCI Slots(fixed): x7（SupportVertical: x7) | Top: 3*120 or 3*140mm(Fan optional) |
| Chassis: L450*W238*H480mm | Support 120/240/280/360mm liquid cooler |
| Product: L456*W238*H500mm | Rear: 1*120mmor 1*140mm(Fan optional) |
| PSU Port: Bottom/ ATX | Support 120mm liquid cooler |
| Max.VGA Card: 440mm | Power Box:2*120 (Fan optional) |
| Max.CPU Cooler: 180mm | Motherboard:3*120mm or 2*140mm (Fan optional) |
| Cable Management: 35mm | Drive Bays: 5.25" ODD x0 |
| / | 3.5" HDD x2 |
| / | 2.5" SSD x3 |
D430ZF-BLACK-详情1.jpgD430ZF-BLACK-详情2.jpgD430ZF-BLACK-详情3.jpgD430ZF-BLACK-详情4.jpgD430ZF-BLACK-详情5.jpgD430ZF-BLACK-详情6.jpg
