HOME >> Product >> Computer case >> Fish Tank >> ATX
Motherboard SupportITX/M-ATX/ATX | Reserved Fan Ports: |
I/O Port：USB1.0 x2+USB3.0 x1 | Front: N/A |
PCI Slots(fixed)：x7 | Top: 3*120mm or 2*140mm (Fan optional) |
Chassis: L420*W212*H470mm | Support 120/240 /280/360mm Liquid cooler |
Product: L425*W212*H490mm | Rear: 1*120mm (Fan optional) |
Carton: L542*W275*H538mm | Support 120 mm Liquid cooler |
PSU Port: Bottom mounted/ ATX /Max 140mm | Motherboard: 3*120mm (Fan optional) |
| Max.VGA Card：400mm | Power Box: 2*120mm (Fan optional) |
| Max. CPU Cooler：165mm | Drive Bays; 5.25" ODD x0 |
| Loading QTY: 20GP 352pcs | 3.5" HDD x2 |
| 40HQ 894pcs | 2.5" SSD x3 |
 |  |
D430ZF-BLACK-详情1.jpgD430ZF-BLACK-详情2.jpgD430ZF-BLACK-详情3.jpgD430ZF-BLACK-详情4.jpgD430ZF-BLACK-详情5.jpgD430ZF-BLACK-详情6.jpg
