Hinge-connected side panel for easy excess
L-shaped curved glass provide panoramic design
Support up to ten 120mm fans
Fine meshed case body provide efficient air flow thought out the case
Motherboard：ITX/M-ATX/ATX(Support BTF) | Reserved Fan Ports： |
I/O Port：Type-C(option),USB3.0 x2+HD Audio | M/B: 3*120 mm (Fan optional) |
PCI Slots：7(Option Vertical) Chassis:0.6~0.7mm | support 120/240/360 mm liquid cooler |
Chassis: L430*W238*H471mm | Top: 3*120 or 2*140 mm (Fan optional) |
Case: L443*W238*H491mm | support 120/240/280/360mm liquid cooler |
Carton: L543*W301*H536mm | Rear: 1*120 or 1*140 mm (Fan optional) |
Max.VGA Card：410mm | support 120/140 mm liquid cooler |
Max. CPU Cooler：180mm | Bottom: 3*120 mm (Fan optional) |
Cable Management：35mm | PSU Port：Bottom / ATX |
 |  |
D430ZF-BLACK-详情1.jpgD430ZF-BLACK-详情2.jpgD430ZF-BLACK-详情3.jpgD430ZF-BLACK-详情4.jpgD430ZF-BLACK-详情5.jpgD430ZF-BLACK-详情6.jpg
